Webasto thermo top evo Installation

1317554A_EN
13
Kia Picanto
Preparing installation location
1 Remove original vehicle bolt (will be re-
used here)
2 Drill hole to 9.1 mm dia.; rivet nut
Installing
rivet nut
1
Perforated bracket a
Angling
down per-
forated
bracket
1
Perforated bracket b
Preparing
perforated
bracket
1
Loosely mount perforated bracket a
2
M6x12 bolt, flanged nut [2x each]
3 Loosely mount perforated bracket b
4
Bracket section A
5
7 mm dia. hole
Premount-
ing bracket
A
21
2
1
48 38
42
45°
47°
1
45°
47°
15
22
40
28
1
22
1
4
2
3
5
2
6
27.5
