Kia Picanto
1317554A_EN
2
Table of Contents
Validity
Vehicle and engine types, equipment variants and national specifications not listed in this installation
documentation have not been tested. However, installation according to this installation documentation
may be possible.
The installation location of the digital timer is to be coordinated with the end customer before installa-
tion.
Manufacturer Model Type EG-BE No. / ABE
Kia Picanto IM e4 * 2007 / 46 * 0256 * ...
Engine type Engine model Output in kW Displacement in cm³
WJO Petrol 51 998
Validity 2
Heater/Installation Kit 3
Foreword 3
General Instructions 3
Special Tools 3
Explanatory notes on document 4
Preliminary work 5
Heater installation location 5
Preparing electrical system 6
Electrical system 8
Fan control 9
Remote option (Telestart) 12
Preparing installation location 13
Preparing heater 14
Installing heater 15
Coolant circuit 17
Combustion air 21
Fuel 22
Exhaust gas 25
Final Work 27
Template for fuel standpipe 28
Operating Instructions for the End Customer 29
