Kia Picanto
1317554A_EN
21
Combustion air
1 10 mm shim, original vehicle stud bolt
Mounting
shim
1
Angle bracket
2 Combustion air pipe
3 Flanged nut
4 M6x20 bolt, flanged nut
5 Silencer
6 25 mm dia. rubber-coated p-clamp
Mounting
silencer
42
1
1
43
3
1 2
4
6
5
