Webasto thermo top evo

1317554A_EN
15
Kia Picanto
All spring clips = 25 mm dia.
Connecting pipe = 90°, 18x18mm dia.
Premount-
ing hoses
1
5x13 self-tapping bolt [3x]
2 Bracket section B
Mounting
bracket B
1
25 mm dia. clamp
2 Mount wiring harness of circulating pump
3 Combustion air pipe
4 90° moulded hose, 10 mm dia. clamp
Premount-
ing heater
Installing heater
Suspend section B of bracket from heater in
bracket section
A
1
5x13 self-tapping bolt [2x]
Mounting
heater
26
G
F
27
1 1
1
2
28
1
4
2
3
29
1
1
