Kia Picanto
1317554A_EN
9
Fan control
Wiring dia-
gram
Webasto components Vehicle components Colours and symbols
Legend
HG Heater TT-Evo GR Fan controller rt red
X1 6-pin heater connector D 4-pin connector GR sw black
X2 2-pin heater connector KB A/C control panel ge yellow
X10 4-pin connector of
heater control
A 26-pin connector KB gn green
B 22-pin connector KB or orange
K1 Fan relay GM Fan motor ws white
F1 Fuse, 20A C 2-pin connector GM br brown
F2 Fuse, 30A IGN1 Fuse bl blue
F3 Fuse, 1A IGN2 Fuse
F4 Fuse, 25A Fa Fuse
IPCU Pulse width modulator Fb Fuse
IPCU settings:
Duty cycle: 100%
Frequency: 14 kHz
Voltage: 3.6V
X Cutting point
Function: High-side Wiring colours may vary.
Webasto
31
30
15
Kia
HG
X2
1 2
X1
52
F2 F1
gn/ws
0,75²
ge
0,5²
rt/sw
0,5²
rt
4²
X10
86
85 30
87a87
K1
gn/ws
0,75²
F4
rt
4²
rt/sw
0,5²
F3
br
0,5²
br
0,5²
85 86
A
E
IPCU
br
0,5²
6
br
0,5²
KB
GR
D
or
bl
GM
M
C
rt
0,5²
sw
0,5²
4
5
3
or
rt
4²
1
gn/ws
0,5²
2
sw
4²
A
IGN
1
IGN
2
FaFb
bl
rt
B
