Webasto thermo top evo Installation

Kia Picanto
1317554A_EN
10
Route wiring harness of heater and fuel line in
17 mm dia. corrugated tube
1 to original vehi-
cle wiring harness on the right hand side of
vehicle.
Routing
wiring har-
ness
1
Wiring harness on heater
2 Fuel line
3 17 mm dia. corrugated tube
Routing
wiring har-
ness
Detach original vehicle bolts 1. Insert angle
bracket
2 of fuse holder between bolts 1 and
instrument panel mounting. Tighten original
vehicle bolts
1 again.
Mounting
passenger
compart-
ment fuse
holder
Connect-
ing wiring
harnesses
9
11
10
1
2
3
11
1
2
1
12
2
1
