Webasto thermo top evo

Kia Picanto
1317554A_EN
11
Drill hole at position 1 to 6.5 mm dia.
1 M6x12 bolt, flanged nut
2 IPCU socket
Mounting
IPCU sock-
et
1
IPCU
Connect-
ing IPCU
1
Original vehicle bolt
Brown (br) wire of IPCU/85
IPCU earth
connection
Connection to 4-pin connector 1 from fan
controller. Produce connections as shown in
wiring diagram.
2 Orange (or) wire GR connector
3 Orange (or) wire of A/C control unit
Red (rt) wire of IPCU/E
Black (sw) wire of IPCU/A
Fan con-
troller con-
nection
13
1
2
14
1
15
1
6
6
16
1
4
2
3
5
4
5
