Webasto thermo top evo

1317554A_EN
14
Kia Picanto
1 Original vehicle bolt
2 Perforated bracket a
3
M6x40 bolt, spring lockwasher, 20 mm
shim, original vehicle threaded hole
4 Bracket section A
5
M6x20 bolt, spring lockwasher, perforat-
ed bracket
b
Mounting
bracket A
Preparing heater
1 Water connection pieces, sealing ring [2x
each]
2 5x15 self-tapping bolt, retaining plate of
water connection pieces
Mounting
water con-
nection
pieces
Discard section X
Hose B =180°, 18 mm dia. moulded hose
Hose
G = 90°, 18 mm dia. moulded hose
A =430
C =75
D =85
E =60
F =360
Cutting
hoses to
length
All spring clips = 25 mm dia.
All connecting pipes = 90°, 18x18 mm dia.
Premount-
ing hoses
23
3
4
1
5
2
24
1
1
2
A
F
X
C D E
B
G
D
25
E
