Kia Picanto
1317554A_EN
4
Special features are highlighted using the following symbols:
The arrow in the vehicle icon indicates the position on
the vehicle and the
viewing angle.
Specific risk of injury or fatal accidents.
Specific risk of damage to components.
Specific risk of fire or explosion.
Reference to general installation instructions of Webas-
to components or to the manufacturer's vehicle-specific
documents.
Reference to a special technical feature.
Mechanical system
Electrical system
Coolant circuit
Fuel
Exhaust gas
Combustion air
Software
All dimensions are in mm!
Tightening torque of 5x13 heater bolts = 8Nm!
Tightening torque of 5x15 bolt of water connection piece retaining plate = 7Nm!
Explanatory notes on document
To provide you with a quick overview of the individual working steps, you will find an identification mark
on the outside top right corner of the page in question.
