Webasto thermo top evo

1317554A_EN
16
Kia Picanto
1 Bracket
2 7 mm dia. hole
3 M6x20 bolt, spring lockwasher, flanged nut
4 M6x20 bolt, large diameter washer
5 5x13 self-tapping bolt
Mounting
heater
1
10 mm dia. clamp
2 Fuel line
Connect-
ing fuel
line
30
1
1
31
2
1
