Webasto thermo top evo Installation

Kia Picanto
1317554A_EN
20
Connect-
ing heater
inlet
1
Hose of engine outlet
Connect-
ing engine
outlet
Ensure sufficient distance from neighbouring
components.
1 25 mm dia. rubber coated p-clamp, flang-
ed nut of original vehicle stud bolt
2 Mount hose on heat exchanger outlet
Aligning
hoses
39
D
C
40
1
A
41
1
A
2
