Webasto thermo top evo Installation

Kia Picanto
1317554A_EN
19
Cutting out insulation mat at the marking.
1 Original vehicle stud bolt, 5 mm shim
Mounting
shim
Cutting out insulation mat at the marking.
1 Original vehicle stud bolt, 5 mm shim
Mounting
shim
Connect-
ing heat
exchanger
inlet
1
Perforated bracket
2 Mount wiring harness of circulating pump
3 M6 Flanged nut, original vehicle stud bolt
Mounting
circulating
pump
35
1
36
1
37
G
F
38
2
3
1
