Webasto thermo top evo Installation

Kia Picanto
1317554A_EN
18
1 Perforated bracket
Angling
down per-
forated
bracket
All spring clips = 25 mm dia.
Connecting pipe = 90°, 18x18mm dia.
1 Perforated bracket
2 M6x25 bolt, flanged nut
3 Circulating pump
4 Mounting of circulating pump
Premount-
ing circu-
lating
pump
All spring clips = 25 mm dia.
Connecting pipe = 18x18mm dia.
Premount-
ing circu-
lating
pump
Separate hose of engine outlet / heat ex-
changer inlet at the marking. Remove and dis-
card hose section of heat exchanger inlet
4
and spring clip
2 .
1 Hose on heat exchanger outlet removed
3 Engine outlet hose section
Cutting
point
60
84
90°
1
32
3
C
4
1 2
B
33
A
34
3
1 2
4
