Webasto thermo top evo Installation

Kia Picanto
1317554A_EN
7
Insert K1 relay 1 after the installation.
2 Angle bracket
3 M5x16 bolt, large diameter washer [2x],
nut
4 Passenger compartment fuse holder
Premount-
ing pas-
senger
compart-
ment fuse
holder
Complete connector of metering pump again
after routing. Pin assignment is not relevant.
1 Connector housing
2 Lock
3 Blue/brown (bl / br) wires
4 Coding
5 Timer lock
Disman-
tling con-
nector
3
3
4
21
4
1 43
5
5
2
