CF-4 11
- Put the soil compactor out of operation as described in
paragraph 2.7.
Danger!
Never use the handle for lifting the machine by crane.
The machine may overturn!!
- Put the crane hook (2/1) into the protection frame (2/2).
Danger!
Only use a lifting tackle and a crane of a sufficient
bearing capacity.
- Lift the soil compactor on the transport vehicle.
Danger!
Do not enter the zone under the suspended load.
Figure 2
2.2 Transport
1
2
Short distances on the job site can be covered by the soil
compactor in accordance with paragraph 2.6.
For transporting the compactor over long distances, however,
the machine can be transported by means of a special
undercarriage (refer to paragraph 2.4.4). In addition, the
compactor can be lifted on an appropriate transport vehicle
(truck, trailer) by means a crane.
2.2.1 Loading by Crane
Caution!
For commissioning, only carry out the pre-start work described in paragraph 2.4.
Keep to the initial maintenance intervals (refer to paragraph 3.2.1).
2.3 Commissioning
