8 CF-4
1.3 Specifications
CF 4 Hatz CF 4 Robin CF 4 Honda
Weight
Operating weight CECE in kg 127 110 107
Dimensions
Overall length (in mm) 1167 1167 1167
Overall width (in mm) 500 500 500
Height with handle folded down
(in mm)
963 963 963
Base plate length (in mm) 390 390 390
Contact area (in mm)
Propulsion
Engine manufacturer Hatz Robin Honda
Type 1 B 20 EX17D GX 160
Maximum output B DIN 70020
(in kW (HP)) at rpm
3.4 (4.6) at 3600 4.2 (5.7) at 4000 4.05 (5.5) at 3600
Type of combustion 4 stroke Diesel 4 stroke gasoline 4 stroke gasoline
Speed 3000 3000 3000
Driving speed, forward
(depending on soil conditions (in
m/min)
25 25 25
Gradeability (depending on soil
conditions, in %)
30 30 30
Depth compaction (in cm) 30 30 30
Performance (in m
2
/h)
750 750 750
Vibration
System Single shaft vibrator Single shaft vibrator Single shaft vibrator
Mode of driving Mechanical Mechanical Mechanical
Frequency (in Hz) 90 90 90
Centrifugal force (in kN) 20 20 20
