Weber mt CF 4 - Honda Engine

32 CF-4
3.3.2.3 Honda Engine
- Remove the wing nut (46/2) and the air filter cover (46/1).
- Pull out the air filter element (47/1) and the foam pre-cleaner (47/2).
- Wash the foam pre-cleaner (47/2) in benzine and let it dry.
Environment Hazard
Dispose of the washing solution in an environmentally-friendly
manner.
- Knock or blow the air filter element (47/1) clean.
Caution!
If this procedure does not provide a sufficient cleaning (e. g. because
of humid or oily dirt), a new filter element must be used.
- Insert the filter (48/1) again and fasten it with the wing nut (48/2).
- Fit the air filter cover (46/1) with the wing nut (46/2).
Figure 46
Figure 47
Figure 48
2
1
1
2
2
1
