Weber mt CF 4 - Stopping, Robin Engine

22 CF-4
open
closed
Figure 28
Figure 31
Figure 30
Figure 29
1
1
1
stop
2.7.2 Stopping, Robin Engine
- Push the speed adjusting lever (29/1) to the right, into the
direction of the arrow, and let the engine idle for some minutes.
- Close the fuel stop cock (29/2).
- Operate the stop switch (30/1).
- Close the water stop cock (31/1) if the machine is equipped
accordingly.
2
closed
open
