CF-4 31
3.3.2.2 Robin Engine
- Remove the wing nut (44/1) and the air filter cover (44/2).
- Pull out the air filter element (45/1) and the pre-cleaner (45/2).
- Wash the pre-cleaner (45/2) in benzine and let it dry.
Environment Hazard
Dispose of the washing solution in an environmentally-friendly
manner.
- Knock or blow the air filter element (45/1) clean
Caution!
If this procedure does not provide a sufficient cleaning (e. g.
because of humid or oily dirt), a new filter element must be
used.
- Insert the filter again.
- Fit the air filter cover (44/2) with the wing nut (44/1).
Figure 45
Figure 44
1
2
1
2
