CF-4 7
1.2 Machine Description
The CF 4 soil compactors are machines of the walk-behind type used for compaction work in road construction and
landscape applications.
Propulsion
The CF4 soil compactors are driven by a Hatz Diesel engine or a Honda or Robin gasoline engine.
Important!
Please refer to paragraph 1.3 (Specifications) for the performance details of the engine and the whole
machine.
Function
The engine (1/9) drives the vibrator via a V-belt. The vibrator is screwed down to the base plate (1/6) and sets it
vibrating. The vibrating base plate performs the vibration work and travelling motion.
Accessories
A damper plate (2.4.3) and a water sprinkler system (1/1 and 1/8) are available as optional extras. A bolt-on
undercarriage (1/4) is offered to facilitate the machine's transport.
Operation
The soil compactor is started by means of a reversible starter (2/5).
The machine is steered with the handle (1/3). The engine speed is directly controlled on the engine (refer to
paragraph 2.5 and the following paragraphs).
