Weber Genesis E-330 User Manual

WWW.WEBER.COM
11
GAS INSTRUCTIONS
PREPARE TO CONNECT THE LP CYLINDER
The regulator must be secured to the side panel with the supplied hose retention
bracket.
Installation Inside of Cabinet
A) Open base cabinet doors.
B) Slide hose retention bracket (1) along hose to align with inside right panel front
mounting holes. Secure with two Phillips head screws/washers/bolts (2).
m WARNING: The hose must be secured to the side panel with the
hose retention bracket. Failure to do so could cause damage
to the hose resulting in a fire or explosion, which can cause
serious bodily injury or death, and damage to property.
Note: Be sure the cylinder brackets are installed in the base panel and the base of the
cylinder fits within the cylinder brackets.
1
2
1
2
Installation Outside of Cabinet
A) Open base cabinet doors.
B) Pass the regulator hose and hose retention bracket (1) out through the side panel
opening.
C) Align with side panel mounting holes located beneath the side panel opening.
Secure with two Phillips head screws/washers/bolts (2).
m WARNING: The hose must be secured to the side panel with the
hose retention bracket. Failure to do so could cause damage
to the hose resulting in a fire or explosion, which can cause
serious bodily injury or death, and damage to property.
◆

Weber Genesis E-330 Specifications

General

Device type	Wheels
Heat source	Natural gas
Total power	12300 W
Smoke function	No
Side burner power	3500 W
Dimensions (WxDxH)	2240 x 870 x 1640 mm
Adjustable thermostat	Yes
Side burners quantity	1
Number of cooking zones	4 zone(s)
Product color	Black
Housing material	Stainless steel
Top surface type	Grate
Cooking surface shape	Rectangular
Cooking surface (W x D)	660 x 500 mm
LED indicators	Temperature

Weight and Dimensions

Depth	870 mm
Width	2240 mm
Height	1640 mm
Weight	114000 g
