MAINTENANCE
ELECTRONIC IGNITION SYSTEM OPERATIONS
If the Electronic Ignition System fails to ignite, be sure there is gas flow by attempting
to match-light your burners. Refer to “MAIN BURNER MANUAL IGNITION”. If match-
lighting is successful, the problem lies in the electronic ignition.
m WARNING: All gas controls and supply valves should be in the
OFF position.
• Verify that the AA battery (alkaline only) is in good condition and installed correctly
(1). Some batteries have a plastic protective wrap around them. This plastic must be
removed. Do not confuse this plastic with the battery label.
• Make sure the ignition wires are attached to igniter module properly. Refer to the
“IGNITER MODULE WIRE GUIDE” below.
• Make sure the ceramic igniter assembly is fully positioned into burner tube igniter
channel (2). If properly positioned, you will hear a snap (3).
• Make sure the Electronic Ignition button is working by listening and looking for
sparks at burner.
If the Electronic Ignition System still fails to light, contact the Customer Service
Representative in your area using the contact information on our web site.
Log onto www.weber.com.
◆
IGNITER MODULE WIRE GUIDE 330
1
2
3
4
1
2
34
A BCD
Wire End & Terminal Colour Burner Tube
Black (1) Left Burner (A)
Yellow (2) Right Burner (B)
Blue (3) Centre Burner (C)
Green (4) Sear Burner (D)
1
2
3

Weber Genesis E-330 Specifications

General

Device type	Wheels
Heat source	Natural gas
Total power	12300 W
Smoke function	No
Side burner power	3500 W
Dimensions (WxDxH)	2240 x 870 x 1640 mm
Adjustable thermostat	Yes
Side burners quantity	1
Number of cooking zones	4 zone(s)
Product color	Black
Housing material	Stainless steel
Top surface type	Grate
Cooking surface shape	Rectangular
Cooking surface (W x D)	660 x 500 mm
LED indicators	Temperature

Weight and Dimensions

Depth	870 mm
Width	2240 mm
Height	1640 mm
Weight	114000 g
