26
MAINTENANCE
BURNER TUBE CLEANING OR REPLACEMENT
Confirm that Grill is Off
A) Turn gas supply off at source and disconnect gas fitting.
B) Check that all burner control knobs are in the off ( )position. Check by pushing
burner control knobs in and turning them clockwise until they stop. If they do not
turn, they are already off. If they do turn, continue turning them clockwise until they
stop; then they are off. If your grill has a side burner, make sure the side burner
control knob is turned off.
C) Remove cookbox components – warming rack, grates and Flavorizer
®
bars. (Heat
deflectors do not need to be removed.)
Remove Control Panel
You will need: A Phillips screwdriver.
A) Locate door pin release in door assembly. Using a screwdriver, push down on door
pin release (1) until door assembly detaches from frame assembly. Pull top of
door assembly away from frame assembly (2) and lift door assembly off bottom
adjustable hinge pin.
B) Remove burner control knobs, igniter button, igniter retention nut, and battery (3).
C) Using a Phillips screwdriver, remove screws from wind deflector (4) located
underneath the control panel.
D) Tilt back of wind deflector down and slide away to remove (5).
E) Remove igniter module from control panel (6) and remove all wires from module.
F) Remove screws from underside of control panel with Phillips screwdriver (7).
G) Lift control panel up slightly, tilt up front edge and gently lift up and away (8).
3
4
5
6
7
8
1
2
