WEG MVW3000 User Manual

5
DETAILED PARAMETER DESCRIPTION
✓
NOTE!
In order that Start/Stop works, configure also P0224 and/or P0227 = 1. The selection of P0265 or
P0267 = 5, and P0266 or P0268 = 5, also requires the configuration of P0221 and/or P0222 = 7.
The selection of P0266 and/or P0267 and/or P0268 = 7 also requires the configuration of P0221
and/or P0222 = 8.
✓
NOTE!
The functions “No external alarm”, “No motor alarm”, “No alarm in the redundant ventilation set A”
and “No alarm in the redundant ventilation set B”, occur by edge detection, as they are functions
with low assets. That is, if the electronics are energized with the DI at low level, no alarm occurs.
a) START/STOP b) GENERAL ENABLE
Acceleration ramp
Deceleration
ramp
Motor speed
Time
Time
24 V
DIx
Open
Acceleration ramp
Motor runs freely
Motor speed
Time
Time
24 V
DIx
Open
c) NO EXTERNAL FAULT d) FORWARD/REVERSE
Motor runs freely
Motor speed
Time
Time
24 V
DIx
Open
Counterclockwise
Clockwise
Motor
speed
Time
Time
24 V
DIx
Open
e) 2nd RAMP f) LOAD USER VIA DIx
24 V
24 V
Open
Open
Ti
me
Time
Time
P0100 P0101
P0102 P0103
DIx -
Run/Stop
Motor
speed
DIx - 2nd ramp
Ti
me
Time
Motor speed
DIx - Fast stop
24 V
Motor decelerates
with null ramp
Open
MVW3000 | 5-57
