Page #160 background imageLoading...
Page #160 background image
5
DETAILED PARAMETER DESCRIPTION
Description:
It selects one of the monitoring parameters. From 1 to 6 read-only parameters can be programmed for simul-
taneous exhibition among the 9 available ones.
Table 5.57: Read-only parameter 6 selection
P0505
Function
0
Inactive
1
Motor speed reference
2
Motor speed
3
Motor Current
4
Reserved
5
Motor Frequency
6
Output voltage
7
Motor Torque
8
Inverter output power
9
Value of process variable (PID)
P0512 - On-line Graphic Function Parameter 1 Selection
P0513 - On-line Graphic Function Parameter 2 Selection
P0514 - On-line Graphic Function Parameter 3 Selection
P0515 - On-line Graphic Function Parameter 4 Selection
Adjustable range: 0 to 9 Factory setting: P0512 = 2
P0513 = 3
P0514 = 0
P0515 = 0
Acesso: Menu Configurations HMI Graphic
Description:
It selects one of the parameters to be monitored by the On-line Graphic Function (Watch Function).
Table 5.58: On-line Graphic Function Parameter 4 Selection
P0515
Function
0
Inactive
1
Motor speed reference
2
Motor speed
3
Motor Current
4
Reserved
5
Motor Frequency
6
Output voltage
7
Motor Torque
8
Inverter output power
9
Value of process variable (PID)
P0516 - Full scale of online graphic 1
P0517 - Full scale of online graphic 2
P0518 - Full scale of online graphic 3
P0519 - Full scale of online graphic 4
Adjustable range: 0 to 200 % Factory setting: 100 %
Acesso: Menu Configurations HMI Graphic
MVW3000 | 5-84
