DETAILED PARAMETER DESCRIPTION
Description:
It sets the direction of rotation of the speed sensor.
Such configuration can be used in applications where the speed sensor is not mounted in the standard position,
but installed in a location where it reads the speed in the reverse direction.
Examples:
Sensor installed in the rear of the motor: standard configuration P0957 = 1
Sensor installed in the rear of the load: special configuration P0957 = 0
Table 5.74: Direction of rotation of the speed sensor
P0957
Function
0
Reverse
1
Direct
P1000 - DC link voltage of cell U1
P1001 - DC link voltage of cell U2
P1002 - DC link voltage of cell U3
P1003 - DC link voltage of cell U4
P1004 - DC link voltage of cell U5
P1005 - DC link voltage of cell U6
P1006 - DC link voltage of cell U7
P1007 - DC link voltage of cell U8
P1008 - DC link voltage of cell U9
P1009 - DC link voltage of cell U10
P1010 - DC link voltage of cell U11
P1011 - DC link voltage of cell U12
Acesso: Menu → Status → Measurements → Voltage
Description:
It indicates the DC link voltage, in volts, of the respective cell.
P1012 - DC link voltage of cell V1
P1013 - DC link voltage of cell V2
P1014 - DC link voltage of cell V3
P1015 - DC link voltage of cell V4
P1016 - DC link voltage of cell V5
P1017 - DC link voltage of cell V6
P1018 - DC link voltage of cell V7
P1019 - DC link voltage of cell V8
P1020 - DC link voltage of cell V9
P1021 - DC link voltage of cell V10
P1022 - DC link voltage of cell V11
P1023 - DC link voltage of cell V12
Acesso: Menu → Status → Measurements → Voltage
Description:
It indicates the DC link voltage, in volts, of the respective cell.
MVW3000 | 5-98
