5
DETAILED PARAMETER DESCRIPTION
Description:
It defines the function of the AI2 analog input of the MVC3 board.
Table 5.72: Function of analog input AI2 MVC3
P0744 Function
0
Not Used
1
Field current
P0745 - Analog input AI2 gain (bipolar MVC3 board)
Adjustable range: 0.000 to 9.999 Factory setting: 1.000
Acesso: Menu → Configurations → I/O → Analog inputs
Description:
It sets the gain of analog input AI2 of the MVC3 board.
Refer to P0234 (Analog input AI1 gain (unipolar MVC4 board)).
P0746 - Analog input AI2 offset (bipolar MVC3 board)
Adjustable range: -100.0 to 100.0 % Factory setting: 0.0 %
Acesso: Menu → Configurations → I/O → Analog inputs
Description:
It sets the offset of analog input AI2 of the MVC3 board.
Refer to P0234 (Analog input AI1 gain (unipolar MVC4 board)).
P0950 - Motor Type
Adjustable range: 0 to 2 Factory setting: 0
Acesso: Menu → Configurations → Control
Description:
It selects the type of the motor to be driven by the inverter, where each option presents specific configuration
parameters.
Table 5.73: Motor Type
P0950
Function
0
Induction motor
1
Reserved
2
Brushless synchronous motor
✓
NOTE!
This parameter can be changed only with the motor stopped.
P0957 - Direction of rotation of the speed sensor
Adjustable range: 0 to 1 Factory setting: 1
Acesso: Menu → Configurations → Control
MVW3000 | 5-97
