5
DETAILED PARAMETER DESCRIPTION
Description:
It indicates the temperature of the IGBT module, in degrees Celsius (°C), of the respective cell.
P1074 - Temperature on the power module of cell W1
P1075 - Temperature on the power module of cell W2
P1076 - Temperature on the power module of cell W3
P1077 - Temperature on the power module of cell W4
P1078 - Temperature on the power module of cell W5
P1079 - Temperature on the power module of cell W6
P1080 - Temperature on the power module of cell W7
P1081 - Temperature on the power module of cell W8
P1082 - Temperature on the power module of cell W9
P1083 - Temperature on the power module of cell W10
P1084 - Temperature on the power module of cell W11
P1085 - Temperature on the power module of cell W12
Acesso: Menu → Status → Measurements → Temperature
Description:
It indicates the temperature of the IGBT module, in degrees Celsius (°C), of the respective cell.
P1136 - Inverter input current
Acesso: Menu → Status → Measurements → Current
Description:
It indicates the current reading at the inverter input, in amperes (A) effective value.
P1137 - Inverter input line voltage
Acesso: Menu → Status → Measurements → Voltage
Description:
It indicates the voltage effective value at the inverter input, in kV.
P1138 - PF at the inverter input
Acesso: Menu → Status → Measurements → Power
Description:
It indicates the cosine of the angle between the voltage and current at the inverter input.
The input power factor is calculated according to the equation:
P1138 =
P1140
P1136
MVW3000 | 5-100
