WEG MVW3000 User Manual

5
DETAILED PARAMETER DESCRIPTION
Defective temperature sensor or undertemperature IGBT cell.
Cell phase IGBT
Cell neutral IGBT
Cell phase pulse feedback
Cell neutral pulse feedback
Cell electronics power supply
Defect in the cell insulation.
WARNING!
Only cells with the bypass system installed will be able to enter the bypass mode. For further details,
contact WEG.
Table 5.75: Automatic Bypass
P1500
Function
0
Inactive
1
Active with Flying Start
✓
NOTE!
This parameter can be changed only with the motor stopped.
P1501 - Line tension balancing method
Adjustable range: 0 to 1 Factory setting: 0
Acesso: Menu → Configurations → Functions → Bypass
Description:
Defines the balancing method of the line voltages when the inverter is operating with an uneven number of
cells between phases.
Option 0 makes the inverter keep the phase voltages always balanced, with the same amplitude and with a
shift of 120°, having the phase with the smallest number of cells as the amplitude limit.
Option 1 makes the inverter keep the line voltages balanced by adjusting the angles between phases to a value
different from 120°.
Table 5.76: Line tension balancing method
P1501
Function
0
Amplitude adjustment of the phase voltages
1
Angle adjustment of the phase voltages
✓
NOTE!
This parameter can be changed only with the motor stopped.
P1502 - Limit of bypassed cells per phase
Adjustable range: 0 to 12 Factory setting: 1
Acesso: Menu → Configurations → Functions → Bypass
Description:
It defines the maximum number of cells per phase may be placed in automatic bypass.
MVW3000 | 5-104
