QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0280
(1)
RL3 Function 0 = Not Used
1 = N* > Nx
2 = N > Nx
3 = N < Ny
4 = N = N*
5 = Zero Speed
6 = Is > Ix
7 = Is < Ix
8 = Reserved
9 = Reserved
10 = Remote
11 = Run
12 = Ready
13 = No Fault
14 = No E70
15 = Reserved
16 = Reserved
17 = No E72
18 = 4 to 20 mA OK
19 = Fieldbus
20 = Forward
21 = Process Variable < VPx
22 = Process Variable < VPy
23 = Reserved
24 = Pre-charge OK
25 = Fault
26 = N > Nx and Nt > Nx
27 = Without error with delay
28 = No Alarm
29 = Timer
30 = Redundant ventilation
31 = PLC
32 = Circuit Break ON (Input Circuit Breaker ON)
33 = Transference OK
34 = Synchronism OK
35 = Serial
1 5-60
P0281
(1)
RL4 Function 0 = Not Used
1 = N* > Nx
2 = N > Nx
3 = N < Ny
4 = N = N*
5 = Zero Speed
6 = Is > Ix
7 = Is < Ix
8 = Reserved
9 = Reserved
10 = Remote
11 = Run
12 = Ready
13 = No Fault
14 = No E70
15 = Reserved
16 = Reserved
17 = No E72
18 = 4 to 20 mA OK
19 = Fieldbus
20 = Forward
21 = Process Variable > VPx
22 = Process Variable < VPy
23 = Reserved
24 = Pre-charge OK
25 = Fault
26 = N > Nx and Nt > Nx
27 = Without error with delay
28 = No Alarm
29 = Reserved
30 = Redundant ventilation
31 = Reserved
32 = Circuit break ON (Input Circuit Breaker ON)
33 = Transference OK
34 = Synchronism OK
35 = Serial
0 5-60
MVW3000 | 1-16
