QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P0282
(1)
RL5 Function 0 = Not Used
1 = N* > Nx
2 = N > Nx
3 = N < Ny
4 = N = N*
5 = Zero Speed
6 = Is > Ix
7 = Is < Ix
8 = Reserved
9 = Reserved
10 = Remote
11 = Run
12 = Ready
13 = No Fault
14 = No E70
15 = Reserved
16 = Reserved
17 = No E72
18 = 4 to 20 mA OK
19 = Fieldbus
20 = Forward
21 = Process Variable > VPx
22 = Process Variable < VPy
23 = Reserved
24 = Pre-charge OK
25 = Fault
26 = N > Nx and Nt > Nx
27 = Without error with delay
28 = No Alarm
29 = Reserved
30 = Redundant ventilation
31 = Reserved
32 = Circuit break ON (Input Circuit Breaker ON)
33 = Transference OK
34 = Synchronism OK
35 = Serial
0 5-60
P0283 RL2 ON time 0.0 to 300.0 s 0.0 s 5-64
P0284 RL2 OFF time 0.0 to 300.0 s 0.0 s 5-64
P0285 RL3 ON time 0.0 to 300.0 s 0.0 s 5-64
P0286 RL3 OFF time 0.0 to 300.0 s 0.0 s 5-64
P0288
(2)
Nx Speed 0 to 4095 rpm 120 rpm 5-64
P0289
(2)
Ny Speed 0 to 4095 rpm 1800 rpm 5-64
P0290
(5)
Ix Current 0.0 to 3276.7 A 300.0 A 5-64
P0291 Zero Speed Zone 1 to 100 % 1 % 5-64
P0292 N=N* Band 1 to 100 % 1 % 5-65
MVW3000 | 1-17
