QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P1561
(7)
Transformer 3 rated power 0 to 10000 kVA 1500 kVA 5-108
P1565
(7)
Number of redundant cells per phase 0 to 11 0 5-109
P1700
(7)
Bypass of the cell U1 0 = Disable
1 = Mechanical bypass cell
2 = Manual activation of the bypass relay
3 = Automatic bypass after a manageable fault
4 = Automatic bypass by parallel association
0 5-109
P1701
(7)
Bypass of the cell U2 0 = Disable
1 = Mechanical bypass cell
2 = Manual activation of the bypass relay
3 = Automatic bypass after a manageable fault
4 = Automatic bypass by parallel association
0 5-109
P1702
(7)
Bypass of the cell U3 0 = Disable
1 = Mechanical bypass cell
2 = Manual activation of the bypass relay
3 = Automatic bypass after a manageable fault
4 = Automatic bypass by parallel association
0 5-109
P1703
(7)
Bypass of the cell U4 0 = Disable
1 = Mechanical bypass cell
2 = Manual activation of the bypass relay
3 = Automatic bypass after a manageable fault
4 = Automatic bypass by parallel association
0 5-109
P1704
(7)
Bypass of the cell U5 0 = Disable
1 = Mechanical bypass cell
2 = Manual activation of the bypass relay
3 = Automatic bypass after a manageable fault
4 = Automatic bypass by parallel association
0 5-109
P1705
(7)
Bypass of the cell U6 0 = Disable
1 = Mechanical bypass cell
2 = Manual activation of the bypass relay
3 = Automatic bypass after a manageable fault
4 = Automatic bypass by parallel association
0 5-109
P1706
(7)
Bypass of the cell U7 0 = Disable
1 = Mechanical bypass cell
2 = Manual activation of the bypass relay
3 = Automatic bypass after a manageable fault
4 = Automatic bypass by parallel association
0 5-109
P1707
(7)
Bypass of the cell U8 0 = Disable
1 = Mechanical bypass cell
2 = Manual activation of the bypass relay
3 = Automatic bypass after a manageable fault
4 = Automatic bypass by parallel association
0 5-109
P1708
(7)
Bypass of the cell U9 0 = Disable
1 = Mechanical bypass cell
2 = Manual activation of the bypass relay
3 = Automatic bypass after a manageable fault
4 = Automatic bypass by parallel association
0 5-109
P1709
(7)
Bypass of the cell U10 0 = Disable
1 = Mechanical bypass cell
2 = Manual activation of the bypass relay
3 = Automatic bypass after a manageable fault
4 = Automatic bypass by parallel association
0 5-109
P1710
(7)
Bypass of the cell U11 0 = Disable
1 = Mechanical bypass cell
2 = Manual activation of the bypass relay
3 = Automatic bypass after a manageable fault
4 = Automatic bypass by parallel association
0 5-109
MVW3000 | 1-28
