1
QUICK REFERENCE OF PARAMETERS AND FAULTS
Param. Description Adjustable range Factory
setting
Page
P1365 Temperature on the board of cell V4 Read-only parameter (
◦
C) - 5-103
P1366 Temperature on the board of cell V5 Read-only parameter (
◦
C) - 5-103
P1367 Temperature on the board of cell V6 Read-only parameter (
◦
C) - 5-103
P1368 Temperature on the board of cell V7 Read-only parameter (
◦
C) - 5-103
P1369 Temperature on the board of cell V8 Read-only parameter (
◦
C) - 5-103
P1370 Temperature on the board of cell V9 Read-only parameter (
◦
C) - 5-103
P1371 Temperature on the board of cell V10 Read-only parameter (
◦
C) - 5-103
P1372 Temperature on the board of cell V11 Read-only parameter (
◦
C) - 5-103
P1373 Temperature on the board of cell V12 Read-only parameter (
◦
C) - 5-103
P1374 Temperature on the board of cell W1 Read-only parameter (
◦
C) - 5-103
P1375 Temperature on the board of cell W2 Read-only parameter (
◦
C) - 5-103
P1376 Temperature on the board of cell W3 Read-only parameter (
◦
C) - 5-103
P1377 Temperature on the board of cell W4 Read-only parameter (
◦
C) - 5-103
P1378 Temperature on the board of cell W5 Read-only parameter (
◦
C) - 5-103
P1379 Temperature on the board of cell W6 Read-only parameter (
◦
C) - 5-103
P1380 Temperature on the board of cell W7 Read-only parameter (
◦
C) - 5-103
P1381 Temperature on the board of cell W8 Read-only parameter (
◦
C) - 5-103
P1382 Temperature on the board of cell W9 Read-only parameter (
◦
C) - 5-103
P1383 Temperature on the board of cell W10 Read-only parameter (
◦
C) - 5-103
P1384 Temperature on the board of cell W11 Read-only parameter (
◦
C) - 5-103
P1385 Temperature on the board of cell W12 Read-only parameter (
◦
C) - 5-103
P1500
(7)
Automatic Bypass 0 = Inactive
1 = Active with Flying Start
0 5-103
P1501
(1)
Line tension balancing method 0 = Amplitude adjustment of the phase voltages
1 = Angle adjustment of the phase voltages
0 5-104
P1502
(1)
Limit of bypassed cells per phase 0 to 12 1 5-104
P1550
(7)
Transformer 1 CT Ratio 1 to 3000 200 5-105
P1551
(7)
Ratio between the voltage of the primary
and the auxiliary output of the trans-
former 1
1.00 to 50.00 18.14 5-105
P1552
(7)
Taps of transformer 1 -5.00 to 5.00 % 0.00 % 5-105
P1553
(7)
Transformers rated voltage 0.00 to 99.99 kV 6.60 kV 5-106
P1554
(7)
Transformer 1 rated power 0 to 10000 kVA 1500 kVA 5-106
P1555
(7)
Transformers rated frequency 0 to 100 Hz 60 Hz 5-106
P1556
(7)
Transformer 2 CT Ratio 50 to 3000 200 5-106
P1557
(7)
Taps of transformer 2 -5.00 to 5.00 % 0.00 % 5-107
P1558
(7)
Transformer 2 rated power 0 to 10000 kVA 1500 kVA 5-107
P1559
(7)
Transformer 3 CT Ratio 50 to 3000 200 5-107
P1560
(7)
Taps of transformer 3 -5.00 to 5.00 % 0.00 % 5-108
MVW3000 | 1-27
