5
DETAILED PARAMETER DESCRIPTION
2 = ‘Inv. Ready’ It indicates the inverter is ready to be enabled.
3 = ‘Motor Mag.’ indicates that the motor is being magnetized by DC current. This state lasts for twice the motor
rotoric constant time (P0412).
4 = ‘Motor Rdy.’ indicates that the motor is magnetized and the inverter is waiting for the run command.
5 = ‘Up Ramp’ indicates the motor is in the speed acceleration ramp.
6 = ‘Down Ramp’ indicates that the motor is in the speed deceleration ramp.
7 = ‘In Ref.’ indicates that the motor is rotating at the adjusted speed reference.
8 = Not implanted in this software version.
9 = ‘Coast’ indicates that the motor is coasting, without being driven by the inverter.
10 = ‘Ride Thro.’ indicates that the inverter is operating during momentary line faults.
11 = ‘Flying St.’ indicates that the inverter has received a command to start a spinning motor. This state persists
until the inverter reaches the motor speed.
12 = ‘Test Mode’ indicates that the inverter is in a transitory state to test mode or to self-tuning.
13 = ‘Inv. Test’ indicates that the inverter is in a general test state.
14 = Not implanted in this software version.
15 = Not implanted in this software version.
16 = ‘Fault’ indicates the inverter is in a fault state.
17 = ‘Alarm’ indicates the inverter is in an alarm state.
18 = ‘Calibrat.’ indicates that the inverter is in the feedback signal calibration process.
19 = ‘Hold’ indicates that the inverter is in DC link regulation mode. Refer to the parameter P0151 description.
20 = ‘I Limit’ indicates that the inverter is in current limitation. Refer to the parameter P0169 description.
21 = ‘I Fast Limit’ indicates that the inverter is in fast current limitation.
22 = ‘Ride Thr 2’ indicates Ride-Through without interruption.
23 = ‘Hold 2’.
24 = ‘Sync Run’ indicates that the inverter is trying to synchronize with the line.
25 = ‘Fast Disab’ indicates fast disable (HG = off) mode (MVC3).
26 = ‘Sync OK’ indicates that the inverter is synchronized with the line.
27 = Not implanted in this software version.
28 = Not implanted in this software version.
MVW3000 | 5-3
