Wega Espresso Coffee Machine - Venus 2004 - PLUS 1-2 Type Machine Electrical Diagram (OLD Version)

CNS
14
English
espresso coffee machine -
interface system
R
2.6 Venus 2004 - PLUS 1-2 type machine electrical diagram (OLD version)
A
Hartwall cable 8.9.28.51 code WY22550
REF. DESCRIPTION
B
White
C
Power cable 8.9.28.12 code WY22551
D
Serial transmission cable code WY22555
F
Dosing
G
Short circuit JP1
H
Never place the lever in the PROG position
I
Interface
N
Black
R
Red
V
Green
33 - 34
Enabling
I
C
D
G
F
H
R
B
V
R
N
R (VCC+)
N (GND)
R
B
V
CN2
F2
CN5
TRF2
CN1
JP14
CN4
JP12
JP3
JP7
JP4
JP6
29.06.04
JP8
JP16
JP1
JP17
JP18
JP2
JP9
JP15
CN6
CN12
CN13
CN11
JP5
CN7
CN10
RL9
RL8
RL7
RL6
F1
RL5
RL4
CN14
RL3
RL2
RL1
CN3
JP10
CN8
A
34 33
34
33
2 1
