1.3 WORKING on the CONTROL UNIT, PRESSURE SWITCH, DOSING DEVICES, or CUP HEATER THERMOSTAT
1) Remove the lower grilles and the drain tub (A)
2) Loosen the screws (B) and remove the protection (C)
3) Loosen the screws (D) located on the base of the support covers of the boiler
4) Loosen the screws (E) and remove the rear cover of the base (F) by sliding it outwards
5) After work is complete, put the body components back in place by following the procedure in reverse order
B
A
B
C
D
D
F
E
