Wega Espresso Coffee Machine - Venus 2005 - PLUS 1-2 Type Machine Electrical Diagram (NEW Version)

English
CNS
15
espresso coffee machine -
interface system
R
2.7 Venus 2005 - PLUS 1-2 type machine electrical diagram (NEW version)
I
C
D
G
F
H
R
B
V
R
N
A
34 33
34
33
2 1
08/04/05
IC1
JP12
JP14
JP12
JP14
CN4
JP1
CN2
R (Vcc+)
N (GND)
V
B
R
+5Vcc
A
Hartwall cable 8.9.28.51 code WY22550
REF. DESCRIPTION
B
White
C
Power cable 8.9.28.12 code WY22551
D
Serial transmission cable code WY22555
F
Dosing
G
Short circuit JP1
H
Never place the lever in the PROG position
I
Interface
N
Black
R
Red
V
Green
33 - 34
Enabling
