WeighTech WT3000-P - 10.2 Serial Output to PC

WEIGHTECH USA Weighing indicator WT3000-IR ABS– Technical manual
Wt3000irabs v20151126
33
10.2 SERIAL OUTPUT CONNECTION
The serial output is connected via terminals located on the main board of the indicator in
accordance with the table and figure below:
Indicator
PC
Borne 1 (RxD)
Pin 3
Borne 2 (TxD)
Pin 2
Borne 3 (GND)
Pin 5
