WeighTech WT3000-P - 1 SPECIFICATIONS

WEIGHTECH USA Weighing indicator WT3000-IR ABS– Technical manual
Wt3000irabs v20151126
5
1 SPECIFICATIONS
Table 1
Input sensitivity
µV/d
0,3
Input signal range
mV/V
From -1 up to +14
Input zero range
From -1 up to +5
Units
kg, g and lb
Internal resolution
1 / 500.000
Non-linearity
0,01% FS
Load cell drive capacity
Up to 8 x 350Ω
Load cell excitation
VDC
5
Load cell connection type
6 wires
Power supply
VAC
AC 110 or 220V 50/60HZ - Battery internal
rechargeable 6V/4,5Ah
Power consumption
mA
150
Operation temperature
°C
de 0 a +40
Display
mm
6 digits LCD with backlight
Display height
55
Display label
Zero, Net, Battery level, Stable, Gross, High,
Low and OK.
Communication interfaces
RS232 output
Degree of protection
IP-68
