4.3.1. Set Image Matching Mode
With a few exceptions, most feature points are the same.
For shooting points with the same features, you only need to set a template; for
shooting points with different features, you need to set templates for each shooting
point.
To set image matching mode for feature points, do the following:
1. Switch to Param window and check Operation parameters.
2. Set parameter 26003 CCD Image Match Mode:
If the feature points are exactly the same, set the parameter to O.
If the feature points are different, set the parameter to 1.
4.3.2. Shoot
To shoot, do one of the following:
Shoot by single point
Shoot by two points
Shoot by three points
Shoot by four points
These methods differ in the number of shooting points:
Comparison between Shoot by two points and other operations is as follows:
Differences
Shoot by two points
Shoot by single/three
/four point(s)
Used coordinate
Workpiece coordinate
Machine coordinate
Shooting position
Input manually.
Directly move to the
corresponding position and
set.
When to set
coordinate system
Set before machining.
Reset based on the actual
position after shooting.
Difference between Shoot by three points and Shoot by four points:
The later is actually an upgraded operation of the former. If shooting a point
fails in shooting by three points, shooting by four points is required.
