Weinmann ACCUVAC Basic Service And Repair Instructions

Technical Data 27
12. Technical Data
ACCUVAC Basic
Product category according
to 93/42/EEC
II b
Dimensions
WxHxD in mm
385x280x140
Weight approx. 5.4 kg
Canister volume 900 ml
Suction capacity at 12 V
with free flow
> 20 l/min
Max. vacuum at 12 V 0.8 bar (80 kPa)
Aspiration tube
diam. 5 mm,
length 1800 mm
Overflow valve filter
at least 99.8 % for
particle size 2.8 µm
Motor output 50 W
Rated voltage 12 V
Maximum current
consumption
3.5 A
Temperature range
Operation
Charging
Storage
–18 °C to +40 °C
+ 0 °C to +40 °C
–40 °C to +70 °C
Electromagnetic
compatibility:
Radio interference
suppression
Radio interference resistance
EN 60601-1-2
EN 55011
IEC 1000-4 Parts 2–5 & 11
Classification according to EN 60601-1:
Protection against electric shock: class II
Degree of protection against electric shock: BF
Degree of protection against water: IPX 1(drip-water)
Classification according to
EN ISO 10079-1
high vacuum/high flow
(Subject to technical change without notice)
Norms complied with
EN 60601-1,
EN ISO 10079-1,
EN 1789
Vehicle plug fuse
8 A, DIN 72581,
identification color white
Internal fuse F1
external power supply
4 A slow-acting,
low breaking capacity
G fuse links 5x20 mm,
conforms to IEC 127
Internal fuse F2
power pack
4 A slow-acting,
low breaking capacity
G fuse links 5x20 mm,
conforms to IEC 127
Power pack type Lead cell, 3.4 Ah
Charging voltage 12.0 to 13.8 V
Operating time
after charging for 14 hours
30 min at maximum suction
Operating mode S2 60 min
Service life of
power pack
400 charge/discharge cycles
in approx. 3 years
AC adapter/charger
primary: 230 V/50 Hz
secondary: 13.8 V /0.3 A
Materials
Disposable collection canister:
Collection canister: PC
Disposable collection bags, tubes: PVC
Nozzle with fingertip: PE
Case PC/ABS
Tube holder plate ABS
ACCUVAC Basic
From serial no. 10735/2004
