Weinmann ACCUVAC Basic Service And Repair Instructions

1. Overview
-1,0
-0,8
-0,6
-0,4
-0,2
0
ACCUVAC Basic from front with disposable collection canister
7 Disposable
canister
2 Vacuum control
3 Voltage indicator
8 Motor unit
6 Release catch
4 On/Off
switch
9 Tube holder plate
1 Pressure gauge
5 Membrane keyboard
ACCUVAC Basic from rear without collection canister
13 Muffler
(hidden)
11 Adapter/charger
plug
14 Suction port 12 Power socket
(hidden)
10 Loops for
accessory bag
Accessories
ACCUVAC Basic interior
18 Plug X100 17 Power pack
15 Fuse F100 16 Fuse F101 (hidden)
27 Vent tab 28 Filter cover 29 Bacteria filter 30 Locking tab 32 Secretion cover 33 Ball (overfill guard) 37 Collection canister
36 Aspiration tube
35 Fingertip
26 Re-usable collection canister WM 15269
34 Sealing ring
31 Bracing
38 Holder set WM 15271
Connection cable WM 10650
Accessory bag WM 10655
Wall bracket WM 15208
Disposable collection canister
24 Collection canister 21 Disposable bag 19 Aspiration tube with
Fingertip
22 Vacuum
tube
20 Intermediate tube
25 Holder
11 Adapter/charger plug
23 T-piece
Mains / charger unit FW7405M/14, complete WM 2610
