Assembly 19
rinsing glass (see “4.6 Fitting a rinsing glass” on
page 19).
1. Use the velcro-type strips to attach the accessory
bag to the loops on the motor unit.
4.6 Fitting a rinsing glass
On the left side of the appliance it is possible to fit an
additional collection canister in the form of a rinsing
glass for holding a rinsing liquid, e.g. water.
The rinsing glass kit WM 15229 consists of:
• Collection canister WM 10631
• Holder set WM 15271
• Mounting panel WM 10728
1. Use a pointed object to pierce the two closed
drill holes on the left of the appliance case.
2. Open the appliance.
3. Insert the plate from the holder set into the
guide.
4. Close the appliance.
