Parameter
Description
Tunnel Start Mode Selection of the start mode for the tunnel. Automatic is the default.
Local Send Cert
Mode
Specifies when the certificate should be sent
Remote Send Cert
Mode
Specifies when the certificate should be sent
ICMP Detect Switches the ICMP watchdog on or o
ICMP Detection
Server
To test the IPsec tunnel connection, a server must be specified here that can only be
reached through the tunnel
ICMP Detection Local
IP
The router interface IP of the local subnet is specified here
ICMP Detection Inter‑
val
Interval at which the ICMP packet is sent
ICMP Detection
Timeout
Time aer which the ICMP packet is discarded
ICMP Detection Max
Retries
Maximum attempts aer a failed ICMP ping
3.7.1.3. IPsec Extern Setting
IPsec profiles are used with GRE over IPsec. The profile is created via the ADD button.
