GPS
Serial
For‑
warding
List
Serial
Type
Selection of the serial interface. RS232 or RS485.
Baud
rate
Here the transmission rate can be selected. Value between 300 and 230400 possible. Default = 9600
Data Bits Setting of the data bits. Selection between 7 bits and 8 bits. Default = 8 bits
Parity Here the parity for the interface can be set. Default = none
Stop Bit Setting of the stop bits. Default = 1 bit
Soware
Flow
Control
Can be switched on or o. Default = o
Include
RMC
Recommended minimum data set. When selected, the minimum of the GPS receiver is output
Include
GSA
Active satellites. Information about PRN numbers of the satellites whose signal is used for position
determination is output here.
Include
GGA
Most important data set with time, position, height and quality of the measurement
Include
GSV
Visible satellites. Provides information about satellites that can possibly be received at present and
information about their position, signal strength, etc. Since only the information of four satellites
can be transmitted per record (limitation to 82 characters), there can be up to three such records
3.3.6 3.3.6. QoS
At this point the definition of Quality of Service is possible. Select Services > QoS.
