Main Interface
primary line to be monitored
Backup Interface secondary line, which is used in case of failure of the primary line
Startup Delay switch‑on delay of the interface monitoring
Up Delay switching delay
Down Delay switching delay
Track ID Reference to ICMP monitoring
In the last step, the routing entries are created or adjusted as in the following example. It is important that the
distance of the main line (here: FE 0/1) has a smaller value than that of the backup line. With the TrackID, the
main line is bound to the ICMP monitoring that was created in the previous step Description of the configuration
elements:
Destination Destination address where to be routed
Netmask Subnet mask belonging to the destination address
Interface Interface via which to send
Gateway IP address via which to send
Distance Route preference/cost
Track ID Reference to ICMP monitoring
Main line works (Internet connection via WAN)
If the main line is working and an Internet connection is established through it, the following can be seen:
1. SLA‑Status
2. Track‑Status
3. Status of the cellular connection
