3.4.3.2. VRRP Configuration
Parameter
Description
Enable Enables or disables the configuration
Virtual
Route ID
Freely selectable, specifies the virtual router group. Must be identical for all routers within the
group.
Interface The LAN Interface
Virtual IP The virtual router IP, must be identical for all routers within the same group.
Priority 0‑254 the higher, the stronger. The highest value within the group automatically becomes the
master.
Adver‑
tisement
Interval(s)
Time to check within the group to find out who is the master.
Preemption
Mode
If switched on, the router automatically checks whether the priority is higher than that of the cur‑
rent master. If it is, then it makes itself the master and the current master becomes the backup
router.
Track ID Previously created track for connection check
VRRP Example:
First, set up a new SLA under Link Backup > SLA and then a track under Link Backup > Track. Then configure Router
A via Link Backup > VRRP > VRRP as shown in Figure 1.
