8 ‒ Function Description | P1PY201 ‒ Laser Distance Sensor ToF 29
Function Possible settings Default
Teach-in Starts the teach-in process.
Teach-in
mode
Foreground Teach-In
Object
Sensor
Teach-in distance
Switching point
Background Teach-In
Object
Sensor
Teach-in distance
Switching point
Window Teach-In
Object
Sensor
Near switching point
Far switching point
Window size
Switching point
Teach-in
distance
Jump Detection
In this mode, there is no switch to an absolute measured
value, but rather to a measured value jump occurring between
2measurements.
Object
Current measured value
Sensor
Positive
Negative
Reference
measured
value
Max. jump height
Min. jump height
Time offset
Distance and Intensity
Foreground teach-in
