BDA CS 300 – 06/15 – REV. B Page 57 / 84
4.4.4 Battery Compartment
The battery compartments 1 are for the
emergency supply of the release button.
In the case of jammed jaws because of a
power outage the electrical crimping machine
CS 300 can be opened by pressing the
release button.
4.4.5 Integrated Piece Counter
The piece counter is integrated within the
display.
By touching the icon the piece counter
can be reset to 0.
4.4.6 Tool Holding Device
The holding device 1 is turnable through
360°.It has an engagement point every 45°.
Thus the operator has the possibility to turn
the holding device in the best suitable
working position.
