Wezag CS 300 - Parts List Exploded View Drawing

BDA CS 300 – 06/15 – REV. B Page 81 / 84
15.2 Parts List Exploded View Drawing
Pos.No.
Pcs
Article-No.
Spare-
part
Description
1
1
1481-11001
Housing
2
4
2480-23063
x
Foot 20/4,3x18 lg
3
4
8480-10061
x
Foot of measuring device A20 20x4x7,5 lg
4
6
8570-00020
x
Disk A4,3 DIN 125-St
5
4
8381-79001
x
Hex Socket Screw M4x30 DIN912
6
4
8480-10075
x
Serrated Washer I 4,3 (Ni) DIN6798
7
4
8171-89008
x
Hex Nut M4 DIN934
8
8
8480-88017
Blind Rivet Nut BN4575-M5
9
1
2481-11007
Motor holding plate
10
2
2481-11019
Distance Bush 16/8,2x10
11
1
2481-11026
Reinforcing Bar
12
3
8480-23020
Hex Socket Countersunk Head Screw M8x30
DIN7991
13
1
2481-11024
Bridge
14
2
8121-20013
Cylinder Pin 4m6x18 DIN6325
15
7
8333-12001
Hex Socket Screw M4x18 DIN912
16
3
2480-23042
Socket 12,0/6,2x8,0
17
3
8480-99069
Hex Socket Countersunk Head Screw M6x35
DIN7991
18
1
8480-15005
Serrated Washer A 6,4 DIN6798
19
1
8165-83001
Hex Nut B M6 DIN 439
20
3
8480-10046
Disk B6,4 DIN125 blank
21
1
8480-99015
Spring Ring DIN 127 - A6
22
4
8114-20004
Hex Nut M6 DIN934
23
2
2481-11008
Knee Lever Guidance
24
2
2480-11006
Joint Bolt 12x34
25
2
2480-11002
Distance Bush (7,1)
26
2
2480-11004
Distance Plate 25,0/12,2x1,0
27
2
2481-11014
Actuating Lever
28
1
2480-11008
Connecting Rod Bolt
29
1
8480-11002
Lock Washer DIN 6799 - 8
30
1
2480-10045
Distance Plate 16,0/10,2
31
1
2481-11013
Pressure Rod
32
1
2481-11015
Knee Lever
33
1
2481-11006
Pressure Rod Base
34
1
2480-11007
Pressure Rod Bolt
35
2
8333-10014
Cylinder Pin 6m6x50 DIN6325
36
1
2481-11009
Distance Bush Ø12/M6 x26,5
37
1
8332-76001
Hex Socket Screw M6x20 DIN912
38
1
2481-11012
Crank
39
2
8480-16013
Hex Socket Screw M6x30 DIN912
40
1
2481-11017
Crank Bolt 8x33,5
41
1
8480-10005
Cylinder Pin 3m6x20 DIN6325
42
1
2480-11005
Distance Plate 12,5/8,2x1,0
43
1
2481-11016
Transfer Lever
44
2
8180-23003
Cylinder Pin 3m6x12 DIN6325
45
1
2481-11018
Segment axis
46
1
2481-11011
Push Rod Guidance
